Perimeter Protection
Solution
Solution
«PERIPHERIQ» -
Area Protection Solution
Area Protection Solution
Aimed to protect the territory of critical infrastructure facilities, special and secure facilities, as well as private property from ground and air threats.
«PERIPHERIQ» -
Area Protection Solution
Area Protection Solution
Aimed to protect the territory of critical infrastructure facilities, special and secure facilities, as well as private property from ground and air threats.
Air and Ground threats are detected by active radar technology long before they cross the protected perimeter line.
This is a new security protection concept that even in fact do not require a physical fence - all threats are detected up to the virtual perimeter line.
How does «PERIPHERIQ» works?
Target detection
The PERIPHERIQ perimeter protection system is based on Pulse-Doppler radar-type motion detectors. Our radar not only detects multiple moving targets, but also collects information about it: its size, speed, direction of movement, as well as spatial position of the target.
Target processing
All detected targets are analyzed by AI controller, which sorts targets, determining their class (drone / bird / man / machine) and evaluate level of threat for a particular site. When the most priority target is sorted out, it should be confirmed optically and accordingly AI controller aims the V17 camera module to see the target.
The video analytics recognizes and confirms the shape of a detected target in the frame. Further, the video analytics is able to independently control the V17 camera module, allowing you to track the target based only on the data from the camera. Video analytics works permanently while the camera is moving and zooming.
The video analytics recognizes and confirms the shape of a detected target in the frame. Further, the video analytics is able to independently control the V17 camera module, allowing you to track the target based only on the data from the camera. Video analytics works permanently while the camera is moving and zooming.
The high level of security
The Peripheriq system uses advanced radar technology to detect an intruder long before he crosses the border of the facility. Thus, the Peripheriq system is designed to raise the level of facility security to a whole new level, helping to prevent incidents.
Application area
The main function of the Peripheriq system is the detection and trajectory control of the movement of UAVs and ground objects in protected areas.
Potential threats such as UAVs, humans, cars or boats are detected by active radar technology long before they cross the perimeter line.
The main function of the Peripheriq system is the detection and trajectory control of the movement of UAVs and ground objects in protected areas.
Potential threats such as UAVs, humans, cars or boats are detected by active radar technology long before they cross the perimeter line.
«Peripheriq» Advantages
- Ready to useRadar-type sensor and Camera are coupled by the construction and factory calibrated, therefore the product is completely ready for use.
- No "blind spots"Full 360 ° view of both Radar and Camera (angle of view 360 ° in azimuth and >180° in elevation).
- High protection efficiencyBalanced detection area, low false alarm rate, minimal impact of precipitation.
- High quality of object detectionThe frequency of updating track data is 4 Hz.
- Open protocolAbility to use the "Peripheriq" system as part of third-party VMS or C&C SW solution.
- High quality of the tracked object videoSpecially developed camera control algorithms (based on radar data and neural network image processing) provide smooth picture of tracking object when the camera and zoom are constantly moving.
Scope of «Peripheriq» modules:
The main components of Peripheriq system are a primary detection radar and an optical confirmation and tracking unit, or tracker (PTZ-camera with integrated AI).
The primary detection sensor is a non-cinematic movement sensor-type movement detector. It detects any moving target and collects data about it, including size, speed, direction and location. All detected targets are classified into the following types: human, animal, car, bird, airplane-type UAV or quadcopter-type UAV, and get filtered and sorted by level of danger.
In automatic mode, the highest priority target is tracked by confirmation system, or the Tracker. Video analytics of confirmation system recognizes and verifies the detected threat. Then it tracks it based on the video data only.
Optic verification unit (Tracker). It’s a completely new architecture of optical systems – an AI integrated tracker with neural data processing. The innovation mad it possible to reduce the response time from the rotation drive and the video analytics to less than 40 ms. Unified processing of data obtained by radar, optical system and PTZ mechanism allows to identify the location of target very accurately. All these processes are done completely automatically, with no operator interference. Once a danger is confirmed, an alarm or counter-measure device can be switched automatically through the integration unit.
The primary detection sensor is a non-cinematic movement sensor-type movement detector. It detects any moving target and collects data about it, including size, speed, direction and location. All detected targets are classified into the following types: human, animal, car, bird, airplane-type UAV or quadcopter-type UAV, and get filtered and sorted by level of danger.
In automatic mode, the highest priority target is tracked by confirmation system, or the Tracker. Video analytics of confirmation system recognizes and verifies the detected threat. Then it tracks it based on the video data only.
Optic verification unit (Tracker). It’s a completely new architecture of optical systems – an AI integrated tracker with neural data processing. The innovation mad it possible to reduce the response time from the rotation drive and the video analytics to less than 40 ms. Unified processing of data obtained by radar, optical system and PTZ mechanism allows to identify the location of target very accurately. All these processes are done completely automatically, with no operator interference. Once a danger is confirmed, an alarm or counter-measure device can be switched automatically through the integration unit.
System features
All radar-type sensors of «Peripheriq» have a built-in DSP processor, which processes all reflected echo signals and generates target data. Thus, sensor transmits target trajectories data after the targets were evaluated.
"Peripheriq" uses solid-state technology, which allows not only to scan space with a frequency of up to 35'000 pulses per second, but also to update the track information of the detected target 4 times per second. This allows you to detect a new target in an average of 2 seconds and track the movement of up to 250 targets simultaneously.
All sensors have automatic sensitivity threshold adjustment, which adaptively adjusts to the current level of passive interference (Clutter). In this case, the automatic selection of the sensitivity threshold is created in each of the 24 visibility zones independently, depending on the level of passive interference in each of them.
Depending on the operating conditions in the "Peripheriq" system, you can choose one of 4 levels of trajectory sensitivity adjustment. The higher the sensitivity, the faster (based on smaller statistic sample), the target will be detected but with more probability to detect false target.
The C-Band frequency (5.8 GHz) and original algorithms of radar data processing allow to achieve reliable target detection in challenging weather conditions: rain, snow or fog.
The "Peripheriq" sensor module has a kinematic free design. In other words, the "Radar" module has no moving or rotating parts, including passive cooling, which guarantees high reliability in 24/7 operation and more than 60,000 hours of uninterrupted operation.
